Siemens ED43S125A - Molded Case Circuit Breaker, 125A 3P (18kA AIC)
Siemens ED43S125A - Molded Case Circuit Breaker, 125A 3P (18kA AIC)

Siemens ED43S125A - Molded Case Circuit Breaker, 125A 3P (18kA AIC)

Siemens
Price
Save $2,655.17
/
Condition
  • Low stock - 1 item left
  • Backordered, shipping soon
Call for Price
Siemens ED43S125A is a molded case circuit breaker from the Sentron Series designed for providing a main disconnect and short-circuit protection in three-phase industrial power distribution systems. It features a 125A continuous current rating and a 480V AC voltage rating, with a robust 18kA interrupting capacity at that voltage. The unit is constructed with a compact ED frame, measures 170mm x 150mm x 101mm (6.693" x 5.906" x 3.980"), weighs 3.781 lb, and utilizes a three-pole, bolt-on connection. It is certified to UL and IEC standards and operates reliably within a temperature range of -25°C to 70°C (-13°F to 158°F). This non-automatic, instantaneous-trip circuit breaker is typically applied in panelboards, switchboards, and industrial control panels where dedicated short-circuit protection is required without thermal overload functionality.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, ED Frame, Non-Automatic (Instantaneous Trip Only)
  • Voltage Rating: 480V AC
  • Current Rating: 125A
  • Dimensions: 170mm x 150mm x 101mm (6.693" x 5.906" x 3.980")
  • Standards: UL Listed, IEC Certified
  • Applications: Industrial Power Distribution, Panelboards, Switchboards
  • Switch Type: Circuit Breaker
  • Configuration: Three-Pole
  • Connection: Bolt-On
  • Phase: 3
  • AIC Rating: 18kA @ 480V AC
  • Protection: Short-Circuit (No Overcurrent Protection)
  • Frame Size: ED Frame
  • Trip Type: Instantaneous Only
  • Breaker Type: Molded Case
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Weight: 3.781 lb
  • Family: Sentron Series
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643216549
  • GTIN: 00783643216549
