Siemens ED42B110 - Molded Case Circuit Breaker, 110A 480V 2-Pole
Siemens ED42B110 - Molded Case Circuit Breaker, 110A 480V 2-Pole

Siemens ED42B110 - Molded Case Circuit Breaker, 110A 480V 2-Pole

Siemens
Price
Save $2,873.46
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens ED42B110 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in commercial and industrial electrical systems. It features a 110A current rating and a 480V AC voltage rating, housed within a compact, durable frame measuring 6.693" x 5.906" x 2.782" and weighing 2.701 lb. The breaker utilizes a thermal-magnetic trip unit for combined long-time and instantaneous (LI) protection and is UL Listed and HACR rated for safety compliance. Its typical applications include integration into Siemens SB switchboards and Sentron panelboards, where its 18kA interrupting rating at 480V ensures system protection.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Trip (LI)
  • Voltage Rating: 480V AC
  • Current Rating: 110A
  • Frame Size: 125A/ED
  • AIC Rating: 18kA @ 480V
  • Poles: 2
  • Phase: 1
  • Connection: Lug in Panelboard, Load Side Lug
  • Wire Size: 3 AWG (Cu), 1/0 AWG (Al) - 3 AWG (Cu), 2 AWG (Al)
  • Standards/Certification: UL Listed, HACR Rated
  • Operating Temperature: -25°C to 70°C (-13°F to 158°F)
  • Dimensions: 6.693" H x 5.906" W x 2.782" D
  • Weight: 2.701 lb
  • Panel Type: SB Switchboards, Sentron Panelboards
  • Breaker Type: Standard
  • Phase Connection: ABC
  • Family: Sentron Series
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643209343
  • GTIN: 00783643209343
