Siemens ED42B100 - Molded Case Circuit Breaker 100A 480V 2-Pole
Siemens ED42B100 - Molded Case Circuit Breaker 100A 480V 2-Pole

Siemens ED42B100 - Molded Case Circuit Breaker 100A 480V 2-Pole

Siemens
Price
Save $2,070.97
/
Condition
  • Low stock - 6 items left
  • Backordered, shipping soon
Call for Price
Siemens ED42B100 is a molded case circuit breaker designed for reliable overcurrent protection in industrial and commercial electrical systems. It features a 100A current rating and a 480V AC voltage rating, housed within a compact 125A/ED frame with dimensions of 6.693" x 5.906" x 2.780" and a weight of 2.599 lb. The breaker provides thermal-magnetic protection with long-time and instantaneous (LI) trip functions, ensuring compliance with UL standards and HACR ratings for heating, air conditioning, and refrigeration equipment. Its 18kA interrupting rating at 480V and a broad operating temperature range from -25°C to 70°C make it suitable for installation in Sentron panelboards and SB switchboards, accommodating wire sizes from 10 to 1/0 AWG for copper or aluminum conductors with its load-side lug connection.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Standard, Thermal-Magnetic Protection
  • Voltage Rating: 480V AC
  • Current Rating: 100A
  • Frame Size: 125A/ED
  • Poles: 2
  • AIC Rating: 18kA @ 480V
  • Functions: LI (Long-Time and Instantaneous Trip)
  • Connection: Lug In Panelboard, Load Side Lug
  • Phase: 1, Phase Connection: Any
  • Wire Size: 10 to 1/0 AWG (Aluminum/Copper), MCM Size: Min. 10 AWG, Max. 1/0 AWG
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Dimensions: 6.693" x 5.906" x 2.780"
  • Weight: 2.599 lb
  • Panel Type: SB Switchboards, Sentron Panelboards
  • Standards & Certification: HACR Rated, UL Listed
  • Breaker Type: Standard
  • Family: Sentron Series
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643209336
  • GTIN: 00783643209336
