Siemens ED42B080 - Molded Case Circuit Breaker 80A 2P 480V
Siemens ED42B080 - Molded Case Circuit Breaker 80A 2P 480V

Siemens ED42B080 - Molded Case Circuit Breaker 80A 2P 480V

Siemens
Price
Save $2,241.89
/
Condition
  • Low stock - 9 items left
  • Backordered, shipping soon
Call for Price
Siemens ED42B080 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in industrial electrical systems. It features a thermal-magnetic trip unit with long-time and instantaneous (LI) functions, rated for 80A at 480V AC with an interrupting capacity of 18kA. The compact, two-pole breaker measures 170 x 150 x 70.5 mm (6.693" x 5.906" x 2.776") and weighs 2.63 lb, constructed for lug-in panelboard connection with load-side lugs compatible with wire sizes from 10 AWG to 1/0 AWG. It is UL Listed and IEC Certified for compliance with industry standards, operating reliably in ambient temperatures from -25°C to 70°C (-13°F to 158°F). This standard breaker is typically applied within Siemens Sentron panelboards and SB switchboards for protecting single-phase branch circuits.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Standard Type
  • Voltage Rating: 480V AC
  • Current Rating: 80A
  • Frame Size: 125A/ED
  • AIC Rating: 18kA @ 480V
  • Poles: 2
  • Phase: 1
  • Connection: Lug In Panelboard, Load Side Lug
  • Trip Functions: LI (Long-Time and Instantaneous)
  • Dimensions: 170 mm x 150 mm x 70.5 mm (6.693 in x 5.906 in x 2.776 in)
  • Weight: 2.63 lb
  • Wire Size (MCM): 10 AWG to 1/0 AWG
  • Operating Temperature: -25°C to 70°C (-13°F to 158°F)
  • Standards & Certification: UL Listed, IEC Certified
  • Compatible Panel Types: SB Switchboards, Sentron Panelboards
  • Phase Connection: Any
  • Breaker Type: Standard
  • Protection: Thermal Magnetic


Product Identification
  • UPC: 783643209312
  • GTIN: 00783643209312
