Eaton ED3200 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in three-phase industrial power systems. It features a 200A current rating and a 240V AC voltage rating, housed within a compact, bolt-on frame measuring 3.38" x 6" x 4.13" (LxHxW) and weighing 4.5 lb. The breaker is CSA Certified, IEC Rated, and UL Listed, ensuring compliance with key North American and international safety standards. Its thermal-magnetic protection with long-time and instantaneous (LI) tripping functions makes it suitable for installation in motor control centers (MCCs), switchboards, and enclosed control panels from major manufacturers.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Standard, Thermal Magnetic Protection
  • Voltage Rating: 240V AC
  • Current Rating: 200A
  • Frame Size: 225A/F
  • Poles: 3
  • AIC Rating: 65kA @ 240V
  • Connection: Bolt-On, Load Side Lug Terminals
  • Phase Connection: 3-Phase (ABC)
  • Functions: LI (Long-Time and Instantaneous)
  • Dimensions: 3.38 in (Depth) x 6 in (Height) x 4.13 in (Width)
  • Weight: 4.5 lb
  • Temp Rating: -4°F to 158°F (-20°C to 70°C)
  • Standards/Certification: CSA Certified, IEC Rated, UL Listed
  • Wire Size Range: 14 AWG to 1/0 AWG
  • Compatible Panel Types: Allen Bradley MCC, Eaton MCC, Rockwell Automation Enclosed Control, Switchboard, Westinghouse


Product Identification
  • UPC: 786679455142
  • GTIN: 00786679455142
