Cutler Hammer
Price
Save $1,646.61
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
The Cutler-Hammer ED3175 is a three-pole, 175A molded case circuit breaker designed to provide reliable thermal-magnetic protection for three-phase industrial power distribution systems operating at 240V AC. It features a 225A frame size, a bolt-on connection with load side lugs, and a compact physical footprint of 3.38" D x 6" H x 4.13" W, weighing 4.5 lb. This breaker is certified to UL, CSA, and IEC standards and is engineered for an interrupting capacity of 65kA at 240V, ensuring robust performance in demanding environments. Its standard trip unit provides long-time and instantaneous (LI) protection functions, making it suitable for installation in motor control centers (MCCs), switchboards, and enclosed control panels from major manufacturers like Allen-Bradley, Eaton, and Rockwell Automation.

Key Features & Specifications
  • Type: ED Series C, Standard, Thermal Magnetic Molded Case Circuit Breaker
  • Voltage Rating: 240V AC
  • Current Rating: 175A
  • Frame Size: 225A/F
  • Poles: 3
  • Phase Connection: 3-Phase (ABC)
  • AIC Rating: 65kA @ 240V AC
  • Connection: Bolt-On, Load Side Lug Terminals
  • Protection Functions: LI (Long-Time & Instantaneous)
  • Breaker Type: Standard
  • Standards & Certification: UL Listed, CSA Certified, IEC Rated
  • Dimensions: 3.38 in (Depth) x 6 in (Height) x 4.13 in (Width)
  • Weight: 4.5 lb
  • Temp Rating: -4°F to 158°F (-20°C to 70°C) Operating
  • MCM Size / Wire Range: 14 AWG to 1/0 AWG
  • Panel Type: Compatible with Allen-Bradley MCC, Eaton MCC, Rockwell Automation Enclosed Control, Switchboard, Westinghouse


Product Identification
  • UPC: 786679455203
  • GTIN: 00786679455203
