Eaton ED2200 - Molded Case Circuit Breaker 200A 2-Pole
Eaton ED2200 - Molded Case Circuit Breaker 200A 2-Pole
Eaton ED2200 - Molded Case Circuit Breaker 200A 2-Pole
Eaton ED2200 - Molded Case Circuit Breaker 200A 2-Pole

Eaton ED2200 - Molded Case Circuit Breaker 200A 2-Pole

Eaton
Price
Save $328.66
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton ED2200 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in industrial power distribution systems. It features a 200A current rating and a 240V voltage rating, housed within a compact 225A frame with dimensions of 3.38 in (D) x 6 in (H) x 2.75 in (W) and a weight of 2.9 lb. The breaker is constructed with a thermal-magnetic trip unit for long-time and instantaneous (LI) protection, offers a 65kA interrupting capacity at 240V, and complies with UL, CSA, and IEC standards for safety and performance. Its two-pole design with load-side lug connections is suitable for integration into motor control centers, switchboards, and enclosed controls from major manufacturers like Allen-Bradley and Rockwell Automation.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Trip (LI)
  • Voltage Rating: 240V AC
  • Current Rating: 200A
  • Frame Size: 225A/F
  • AIC Rating: 65kA @ 240V
  • Poles: 2
  • Phase Connection: AB
  • Dimensions: 3.38 in x 6 in x 2.75 in (Depth x Height x Width)
  • Weight: 2.9 lb
  • Terminal Connection: Load Side Lug
  • Wire Size Range: 14 AWG to 1/0 AWG
  • Operating Temperature: -4°F to 158°F (-20°C to 70°C)
  • Standards & Certification: UL Listed, CSA Certified, IEC Rated
  • Protection: Thermal Magnetic
  • Panel Type: Compatible with Allen Bradley MCC, Eaton MCC, Rockwell Automation Enclosed Control, Switchboard, Westinghouse


Product Identification
  • UPC: 786679456224
  • GTIN: 00786679456224
