Edison ECS60 - RK5 Class Fuse 60A 600V (100kA AIC Rating)

Edison ECS60 is a current-limiting fuse designed for industrial circuit protection applications requiring high interrupting capacity. The fuse features a 600V AC voltage rating with a 60A current rating, providing reliable overcurrent protection in demanding electrical environments. Constructed as a single-barrel RK5 class fuse with a weight of 5.19 lb, it offers robust physical durability and precise current limitation characteristics. The device complies with industry standards for low-voltage protection systems and demonstrates a 100kA interrupting rating at 600V. Typical applications include motor branch circuits, feeder protection, and industrial control panels where high fault current interruption is critical.

Key Features & Specifications

• Type: Current-limiting fuse, RK5 class, single barrel construction
• Voltage Rating: 600V AC
• Current Rating: 60A
• Dimensions: Standard RK5 fuse dimensions
• Standards: Industrial low voltage protection standards
• Applications: Motor circuits, feeder protection, industrial control panels
• AIC rating: 100kA@600V
• Class Rating: RK5
• Barrels: 1
• Weight: 5.19 lb
• Family: Econ
• Item Subcategory: Low Voltage
