Siemens DTNF323R - Non-Fusible Disconnect Switch 100A 3P (240V AC, NEMA 3R)

Siemens
Price
Save $0
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens DTNF323R is a heavy-duty industrial disconnect switch designed for the safe isolation of three-phase electrical circuits. It is rated for 240V AC operation with a 100A current capacity and features a robust, non-fusible switch style in a single configuration with three poles. The unit is constructed within a NEMA 3R enclosure for outdoor durability, measures 31.89 x 16.929 x 10.63 inches, and weighs 46.892 lb. It complies with the UL98 standard and is engineered for an interrupting rating of 200kA at 240V, making it suitable for integration with compatible MAP frames in industrial power distribution and motor control applications.

Key Features & Specifications
  • Type: Non-Fusible Disconnect Switch, Single Configuration
  • Voltage Rating: 240V AC
  • Current Rating: 100A
  • Dimensions: 31.89 x 16.929 x 10.63 inch
  • Standards: UL98 Certified, NEMA 3R Enclosure Rating
  • Applications: Industrial power distribution, motor control isolation
  • Switch Style: Non-Fusible
  • Configuration: Single
  • Poles: 3
  • Phase: 3
  • AIC rating: 200kA@240V
  • Nema Rating: NEMA 3R
  • Certification: UL98
  • Compatible Frames: MAP
  • Wire: 3
  • Fuse Class: R
  • Weight: 46.892 lb
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643454163
  • GTIN: 00783643454163
