Cutler Hammer DH361UWK - Non-Fusible Disconnect Switch 30A 600V (3-Pole NEMA 4X)

Cutler Hammer DH361UWK is a heavy-duty disconnect switch designed for reliable circuit isolation and load-breaking operations in industrial power distribution systems. This 3-pole switch features a 600V voltage rating and 30A current capacity, engineered to handle demanding electrical environments with robust performance. The unit features a compact yet durable construction measuring 8.76 x 10.22 x 14.14 inches (WxDxH) and weighing 17 lb, built to withstand harsh conditions with its NEMA 4X rated enclosure. It complies with UL standards and meets NEC 230.62 (C) requirements for barrier compliance, ensuring safe operation in regulated environments. This non-fusible disconnect switch is particularly suited for industrial applications requiring high interrupting capacity, featuring an impressive 200kA AIC rating at 600V for three-phase systems.

Key Features & Specifications

• Type: Non-Fusible Disconnect Switch, DH Series
• Voltage Rating: 600V AC
• Current Rating: 30A
• Dimensions: 8.76 in x 10.22 in x 14.14 in (WxDxH)
• Weight: 17 lb
• Standards: UL Listed, NEC 230.62 (C) Compliant Barrier
• Applications: Industrial Power Distribution, Motor Control, Circuit Isolation
• Switch Type: Non-Fusible
• Configuration: Single
• Poles: 3
• AIC Rating: 200kA@600V
• NEMA Rating: NEMA 4X
• Phase: 3
• Enclosure: NEMA 4X Rated
• Country of Origin: United States

Product Identification

• UPC: 782113205724
• GTIN: 00782113205724
