Cutler Hammer DH262UDK - Non-Fusible Disconnect Switch 60A 600V (NEMA 12 Enclosure)

Cutler Hammer DH262UDK is a non-fusible safety disconnect switch designed for reliable circuit isolation and load-breaking operations in industrial applications. The switch features a 600V voltage rating and 60A current handling capacity, providing robust electrical performance for single-phase systems. Its compact design measures 8.76 x 10.22 x 14.14 inches (WxDxH) with a weight of 21 lb, constructed with a NEMA 12 rated enclosure for dust-tight and drip-proof protection. The unit is UL Listed and complies with NEC 230.62 (C) barrier requirements, ensuring adherence to industry safety standards. Typical applications include industrial control panels, motor control centers, and power distribution systems where safe maintenance and equipment isolation are critical.

Key Features & Specifications

• Type: Non-fusible safety disconnect switch, DH Series
• Voltage Rating: 600V AC
• Current Rating: 60A
• Dimensions: 8.76 in x 10.22 in x 14.14 in (WxDxH)
• Standards: UL Listed, NEC 230.62 (C) Compliant Barrier
• Applications: Industrial control panels, motor control centers, power distribution systems
• Switch Type: Non-Fusible
• Configuration: Single
• Phase: 1
• Poles: 2
• AIC Rating: 200kA@600V
• NEMA Rating: NEMA 12
• Weight: 21 lb
• Compatible Frames: SELA
• Country of Origin: United States

Product Identification

• UPC: 782113206110
• GTIN: 00782113206110
