Eaton DBU27-150E - Class E Medium Voltage Fuse (27kV, 150A)

Eaton
Price
Save $156.91
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton DBU27-150E is a medium voltage fuse designed for overcurrent protection in high-voltage electrical distribution systems. It is rated for 27,000 volts with a continuous current rating of 150 amps and an interrupting capacity of 12.5 kA at 27 kV. The fuse features a single-barrel, ferrule-connection design with a standard velocity characteristic, constructed to a length of 22.5 inches and a diameter of 1.24 inches. It complies with the IEEE Std. C37.41 standard and is typically applied in utility, industrial, and commercial power distribution equipment for transformer and feeder protection.

Key Features & Specifications
  • Type: DBU Class E, single-barrel medium voltage fuse with ferrule connection and standard velocity characteristic
  • Voltage Rating: 27,000 V
  • Current Rating: 150 A
  • Dimensions: 22.5 in (Length) x 1.44 in (Height) x 1.44 in (Width)
  • Diameter: 1.24 in
  • Weight: 2.5 lb
  • Standards: Certified to IEEE Std. C37.41
  • AIC Rating: 12.5 kA @ 27 kV
  • Class Rating: E
  • Connection: Ferrule
  • Barrels: 1
  • Velocity: Standard
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 078667601128
  • GTIN: 00786676011280
