Cutler Hammer CSR2150N - 2-Pole 150A Circuit Breaker (240V, 25kA AIC)
Cutler Hammer CSR2150N - 2-Pole 150A Circuit Breaker (240V, 25kA AIC)

Cutler Hammer CSR2150N - 2-Pole 150A Circuit Breaker (240V, 25kA AIC)

Cutler Hammer
Price
Save $1,063.93
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Cutler Hammer CSR2150N is a molded case circuit breaker designed for providing reliable overcurrent protection in single-phase industrial and commercial electrical systems. It features a 150A current rating and a 240V AC voltage rating, housed in a compact plug-in configuration measuring 5.3 in (L) x 3.52 in (H) x 4.2 in (W) and weighing 2.5 lb. The breaker is UL 489 certified and utilizes a thermal-magnetic trip mechanism with long-time and instantaneous (LI) functions to safeguard circuits. Its 25kA interrupting rating at 240V and compatibility with conductors from 2 AWG to 300 kcmil make it suitable for panelboards, switchboards, and other power distribution equipment.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, CSR Series, Thermal-Magnetic Protection
  • Voltage Rating: 240V AC
  • Current Rating: 150A
  • Dimensions: 5.3 in x 3.52 in x 4.2 in (Length/Depth x Height x Width)
  • Weight: 2.5 lb
  • Standards: UL 489
  • Applications: Industrial & Commercial Power Distribution
  • Switch Type: Circuit Breaker
  • Configuration: Plug-In
  • Phase: 1
  • Amperage: 150A
  • AIC Rating: 25kA @ 240V
  • Connection: Plug-In
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: LI (Long-Time and Instantaneous)
  • Wire Size: 2 AWG - 300 kcmil at 60/75°C
  • Certification: UL 489
  • Country of Origin: United States


Product Identification
  • UPC: 782113098449
  • GTIN: 00782113098449
