Cutler Hammer BWH2150 - Molded Case Circuit Breaker 150A 2-Pole
Cutler Hammer BWH2150 - Molded Case Circuit Breaker 150A 2-Pole

Cutler Hammer BWH2150 - Molded Case Circuit Breaker 150A 2-Pole

Cutler Hammer
Price
Save $1,999.60
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Cutler Hammer BWH2150 is a molded case circuit breaker designed to provide reliable overcurrent protection for industrial electrical systems. It features a 150A current rating and a 240V voltage rating for single-phase applications, with a 25kA interrupting capacity at 240V. The compact, bolt-on unit measures 6.25" x 5.25" x 5.25" and weighs 2.75 lb, utilizing a thermal-magnetic trip mechanism for both long-time and instantaneous (LI) protection. It complies with UL 489 and Federal Specification W-C375 standards, ensuring robust performance in demanding environments. This breaker is suitable for protecting feeders and branch circuits in industrial panels and switchboards, accommodating copper or aluminum conductors from AWG 2 to 300 kcmil within an operating temperature range of -25°C to 70°C (-13°F to 158°F).

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Bolt-On Connection
  • Voltage Rating: 240V AC
  • Current Rating: 150A
  • Dimensions: 6.25 in (Depth) x 5.25 in (Height) x 5.25 in (Width)
  • Standards: UL 489, Federal Specifications Classification W-C375
  • Applications: Industrial Feeder and Branch Circuit Protection
  • Switch Type: Circuit Breaker
  • Configuration: Fixed
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Shipping Dimensions: 6.25 in x 5.25 in x 5.25 in
  • Phase: 1
  • Voltage: 240V
  • Amperage: 150A
  • AIC rating: 25kA @ 240V
  • Connection: Bolt-On
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: Long-Time and Instantaneous Trip (LI)
  • Frame Size: BWH Series
  • Trip Type: Thermal-Magnetic
  • Wire Size: AWG 2 to 300 kcmil, Copper/Aluminum
  • Certification: UL 489, Federal Specifications Classification W-C375
  • Circuit Breaker Mounting Style: Bolt-On
  • Terminal Connection: Bolt-On
  • Standards: UL 489, Federal Specifications Classification W-C375
  • Installation Type: Fixed
  • Breaker Frame: BWH Series
  • Current Rating: 150A
  • Operating Temperature Maximum Celsius: 70 °C


Product Identification
  • UPC: 786676460453
  • GTIN: 00786676460453
