Cutler-Hammer BRP120GF - 1-Pole 20A Circuit Breaker (10kA AIC)
Cutler-Hammer BRP120GF - 1-Pole 20A Circuit Breaker (10kA AIC)
Cutler-Hammer BRP120GF - 1-Pole 20A Circuit Breaker (10kA AIC)
Cutler-Hammer BRP120GF - 1-Pole 20A Circuit Breaker (10kA AIC)
Cutler-Hammer BRP120GF - 1-Pole 20A Circuit Breaker (10kA AIC)
Cutler-Hammer BRP120GF - 1-Pole 20A Circuit Breaker (10kA AIC)
Cutler-Hammer BRP120GF - 1-Pole 20A Circuit Breaker (10kA AIC)
Cutler-Hammer BRP120GF - 1-Pole 20A Circuit Breaker (10kA AIC)
Cutler-Hammer BRP120GF - 1-Pole 20A Circuit Breaker (10kA AIC)
Cutler-Hammer BRP120GF - 1-Pole 20A Circuit Breaker (10kA AIC)

Cutler-Hammer BRP120GF - 1-Pole 20A Circuit Breaker (10kA AIC)

Cutler Hammer
Price
Save $411.11
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
The Cutler-Hammer BRP120GF is a single-pole, plug-in molded case circuit breaker designed to provide reliable thermal-magnetic protection for 120V AC branch circuits. It features a 20A current rating and a 10kA interrupting capacity at 120V, housed in a compact 4" x 1" x 3.5" (LxHxW) plug-on unit weighing 0.45 lb. Constructed for durability, it operates across a temperature range of -25°C to 70°C (-13°F to 158°F) and accepts #14-8 AWG copper wire. This breaker utilizes a long-time and instantaneous (LI) trip function to safeguard against both overloads and short circuits in residential and light commercial electrical panels.

Key Features & Specifications
  • Type: Single-Pole (1P), Plug-In, Thermal-Magnetic Molded Case Circuit Breaker
  • Voltage Rating: 120V AC
  • Current Rating: 20A
  • Dimensions: 4 in (Depth) x 1 in (Height) x 3.5 in (Width)
  • Standards: Designed to relevant UL standards
  • Applications: Residential and light commercial branch circuit protection
  • Switch Type: Circuit Breaker
  • Configuration: Plug-In
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Phase: 1
  • AIC Rating: 10kA @ 120V
  • Connection: Plug-On Terminal
  • Poles: 1
  • Protection: Thermal-Magnetic
  • Functions: Long-Time and Instantaneous (LI) Trip
  • Breaker Type: BRP
  • Wire Size: #14-8 AWG
  • Family: BR Series
  • Country of Origin: United States
  • Weight: 0.45 lb


Product Identification
  • UPC: 786689031206
  • GTIN: 00786689031206
