Cutler Hammer BR260ST - 60A 2-Pole Thermal Magnetic Circuit Breaker
Cutler Hammer BR260ST - 60A 2-Pole Thermal Magnetic Circuit Breaker

Cutler Hammer BR260ST - 60A 2-Pole Thermal Magnetic Circuit Breaker

Cutler Hammer
Price
Save $423.49
/
Condition
  • Low stock - 7 items left
  • Backordered, shipping soon
Call for Price
Cutler Hammer BR260ST is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in single-phase electrical systems. It features a 60A current rating and a 240V AC voltage rating, housed in a compact plug-in configuration measuring 3.25 in x 3 in x 3 in and weighing 1 lb. The breaker utilizes a thermal-magnetic trip mechanism for both long-time and instantaneous protection, is rated for 10kA interrupting capacity at 240V, and operates within a temperature range of -25 to 70 °C (-13 to 158 °F). It complies with UL 489 and Federal Specification W-C375 standards and is engineered for use in industrial and commercial panelboards, with an integrated 120V shunt trip for remote tripping capability and compatibility with #8 to 1/0 AWG copper or aluminum conductors.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Plug-In Connection
  • Voltage Rating: 240V AC
  • Current Rating: 60A
  • Dimensions: 3.25 in x 3 in x 3 in (Length/Depth x Height x Width)
  • Standards: UL 489, Federal Specifications Classification W-C375
  • Applications: Industrial & Commercial Panelboards
  • Switch Type: Circuit Breaker
  • Configuration: Plug-In
  • Temp Rating: -25 to 70 °C (-13 to 158 °F)
  • Phase: 1
  • AIC rating: 10kA @ 240V
  • Connection: Plug-In
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Wire Size: #8 to 1/0 AWG CU/AL
  • Certification: UL 489, Federal Specifications Classification W-C375
  • Additional Info: Complete with 120V Shunt Trip


Product Identification
  • UPC: 786676000369
  • GTIN: 00786676000369
