Eaton Cutler-Hammer BR220ST - 2-Pole 20A Circuit Breaker with Shunt Trip
Eaton Cutler-Hammer BR220ST - 2-Pole 20A Circuit Breaker with Shunt Trip

Eaton Cutler-Hammer BR220ST - 2-Pole 20A Circuit Breaker with Shunt Trip

Cutler Hammer
Price
Save $561.57
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton Cutler-Hammer BR220ST is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in 240V AC single-phase electrical systems. It features a 20A current rating and a 10kA interrupting capacity at 240V, housed within a compact plug-in unit measuring 4.5" L x 4" H x 4.25" W and weighing 1 lb, constructed with a thermal-magnetic trip mechanism for both long-time delay and instantaneous response. This breaker is UL 489 listed and meets Federal Specification W-C375, ensuring compliance for use in commercial and light industrial panelboards. It is engineered to protect branch circuits utilizing #14 to 4 AWG copper or aluminum conductors across an operating temperature range of -25 to 70 °C and includes an integrated 120V shunt trip accessory for remote tripping capability.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Plug-In Connection
  • Voltage Rating: 240V AC
  • Current Rating: 20A
  • Dimensions: 4.5 in (L) x 4 in (H) x 4.25 in (W)
  • Standards: UL 489, Federal Specification W-C375
  • Applications: Commercial & Light Industrial Panelboards, Branch Circuit Protection
  • Switch Type: Circuit Breaker
  • Configuration: Plug-In
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Phase: 1
  • AIC Rating: 10kA @ 240V
  • Connection: Plug-In
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Wire Size: #14 to 4 AWG CU/AL
  • Certification: UL 489, Federal Specifications Classification W-C375
  • Additional Info: Includes 120V Shunt Trip
  • Family: BR Series
  • Country of Origin: Dominican Republic
  • Weight: 1 lb


Product Identification
  • UPC: 786676000291
  • GTIN: 00786676000291
