Cutler Hammer BR2020 - 1-Pole Circuit Breaker 20A 120V (10kA AIC)
Cutler Hammer BR2020 - 1-Pole Circuit Breaker 20A 120V (10kA AIC)
Cutler Hammer BR2020 - 1-Pole Circuit Breaker 20A 120V (10kA AIC)
Cutler Hammer BR2020 - 1-Pole Circuit Breaker 20A 120V (10kA AIC)
Cutler Hammer BR2020 - 1-Pole Circuit Breaker 20A 120V (10kA AIC)
Cutler Hammer BR2020 - 1-Pole Circuit Breaker 20A 120V (10kA AIC)

Cutler Hammer BR2020 - 1-Pole Circuit Breaker 20A 120V (10kA AIC)

Cutler Hammer
Price
Save $185.64
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Cutler Hammer BR2020 is a single-pole molded case circuit breaker designed for branch circuit protection in residential and light commercial electrical systems. It provides a 20A current rating and 120V voltage rating with thermal-magnetic protection featuring both long-time and instantaneous trip functions for reliable overload and short-circuit interruption. The compact plug-in unit measures 1" x 2.5" x 2.9" (LxHxW), weighs 0.35 lb, and operates within a temperature range of -25°C to 70°C (-13°F to 158°F). It is UL 489 certified and designed for compatibility with Type BR loadcenters, offering a 10kA interrupting capacity at 120V. Typical applications include protecting 120V AC circuits wired with copper or aluminum conductors from 14 AWG to 4 AWG.

Key Features & Specifications
  • Type: Single-pole, plug-in, thermal-magnetic molded case circuit breaker
  • Voltage Rating: 120V AC
  • Current Rating: 20A
  • Dimensions: 1 in (Depth) x 2.5 in (Height) x 2.9 in (Width)
  • Standards & Certification: UL 489
  • Applications: Branch circuit protection in Type BR loadcenters for residential/light commercial use
  • Breaker Type: BR
  • Phase: 1
  • AIC Rating: 10kA @ 120V
  • Connection: Plug-In
  • Poles: 1
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Wire Size: 14 AWG to 4 AWG (Cu/Al)
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Weight: 0.35 lb
  • Family: BR Series
  • Country of Origin: United States


Product Identification
  • UPC: 786676370257
  • GTIN: 00786676370257
