Cutler Hammer BR1515 - BR Series 15A Circuit Breaker (10kA AIC)
Cutler Hammer BR1515 - BR Series 15A Circuit Breaker (10kA AIC)
Cutler Hammer BR1515 - BR Series 15A Circuit Breaker (10kA AIC)
Cutler Hammer BR1515 - BR Series 15A Circuit Breaker (10kA AIC)
Cutler Hammer BR1515 - BR Series 15A Circuit Breaker (10kA AIC)
Cutler Hammer BR1515 - BR Series 15A Circuit Breaker (10kA AIC)

Cutler Hammer BR1515 - BR Series 15A Circuit Breaker (10kA AIC)

Cutler Hammer
Price
Save $187.20
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Cutler Hammer BR1515 is a single-pole molded case circuit breaker designed to provide reliable overcurrent protection for 120V AC branch circuits. It features a 15A current rating and a 10kA interrupting capacity at 120V, utilizing a thermal-magnetic trip mechanism for both long-time delay and instantaneous response to overloads and short circuits. The compact plug-in unit measures 1" x 2.5" x 2.9" and weighs 0.35 lb, constructed for compatibility with Type BR loadcenters and accepting copper or aluminum wire from 14 to 4 AWG. It is manufactured in the United States to comply with the UL 489 standard, ensuring safe operation in residential and light commercial electrical panels for appliance and lighting circuit protection.

Key Features & Specifications
  • Type: Single-Pole, Molded Case, Thermal-Magnetic Circuit Breaker
  • Voltage Rating: 120V AC
  • Current Rating: 15A
  • Dimensions: 1 in (Depth) x 2.5 in (Height) x 2.9 in (Width)
  • Standards: UL 489
  • Applications: Branch circuit protection in residential/light commercial panels
  • Switch Type: Circuit Breaker
  • Configuration: Plug-In
  • Phase: 1
  • AIC Rating: 10kA @ 120V
  • Connection: Plug-In
  • Poles: 1
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Breaker Type: BR
  • Panel Type: Type BR Loadcenters
  • Wire Size: 14 AWG to 4 AWG (Cu/Al)
  • Certification: UL 489
  • Family: BR Series
  • Country of Origin: United States
  • Weight: 0.35 lb


Product Identification
  • UPC: 786676370059
  • GTIN: 00786676370059
