Siemens
Price
Save $1,415.39
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens BQD270 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in industrial and commercial electrical systems. It features a 70A current rating and a 480V AC voltage rating, housed in a compact, durable enclosure measuring 2" x 4.49" x 4.49" (50.8mm x 114mm x 114mm) and weighing 1.131 lb. The breaker is constructed with a thermal-magnetic trip unit for combined long-time and instantaneous (LI) protection, offers a 14kA interrupting capacity at 480V, and complies with UL 516 and CSA C22.2 standards. Its bolt-on connection and lug terminals ensure secure installation, making it suitable for use in Siemens P1 panelboards and similar single-phase applications within an operating temperature range of -25°C to 70°C.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Standard
  • Voltage Rating: 480V AC
  • Current Rating: 70A
  • Dimensions: 2 in x 4.49 in x 4.49 in (50.8mm x 114mm x 114mm)
  • Standards: UL 516, CSA C22.2
  • Applications: Industrial & Commercial Panelboards
  • Switch Type: Circuit Breaker
  • Configuration: Bolt-On
  • Phase: 1
  • AIC Rating: 14kA @ 480V
  • Connection: Bolt-On
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: LI - Long-Time and Instantaneous Trip
  • Breaker Type: Standard
  • Temp Rating: -25°C to 70°C
  • Panel Type: Siemens P1 Panelboards
  • Terminal Connection: Lug
  • Certification: CSA-C22.2, UL 516
  • Weight: 1.131 lb


Product Identification
  • UPC: 783643277304
  • GTIN: 00783643277304
