Siemens BQD240 - Molded Case Circuit Breaker, 40A 480V 2-Pole
Siemens BQD240 - Molded Case Circuit Breaker, 40A 480V 2-Pole
Siemens BQD240 - Molded Case Circuit Breaker, 40A 480V 2-Pole
Siemens BQD240 - Molded Case Circuit Breaker, 40A 480V 2-Pole
Siemens BQD240 - Molded Case Circuit Breaker, 40A 480V 2-Pole
Siemens BQD240 - Molded Case Circuit Breaker, 40A 480V 2-Pole
Siemens BQD240 - Molded Case Circuit Breaker, 40A 480V 2-Pole
Siemens BQD240 - Molded Case Circuit Breaker, 40A 480V 2-Pole

Siemens BQD240 - Molded Case Circuit Breaker, 40A 480V 2-Pole

Siemens
Price
Save $666
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens BQD240 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in industrial and commercial electrical systems. It features a 40A current rating and a 480V AC voltage rating, housed within a compact, durable enclosure measuring 2" x 4.49" x 4.49" (50.8mm x 114mm x 114mm) and weighing 1.1 lb. The breaker is constructed for bolt-on connection with lug terminals and complies with CSA-C22.2 and UL 512 standards, ensuring safe operation in environments from -25°C to 70°C. Its thermal-magnetic protection with long-time and instantaneous (LI) trip functions and a 14kA interrupting rating at 480V makes it suitable for safeguarding branch circuits in Siemens P1 panelboards and similar single-phase applications.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Standard, Thermal-Magnetic Protection
  • Voltage Rating: 480V AC
  • Current Rating: 40A
  • Dimensions: 2 in x 4.49 in x 4.49 in (50.8mm x 114mm x 114mm)
  • Standards: CSA-C22.2, UL 512
  • Applications: Branch circuit protection in industrial/commercial panelboards
  • Switch Type: Circuit Breaker
  • Configuration: Bolt-On
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Phase: 1
  • AIC Rating: 14kA @ 480V
  • Connection: Bolt-On
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: LI (Long-Time and Instantaneous Trip)
  • Breaker Type: Standard
  • Certification: CSA-C22.2, UL 512
  • Terminal Connection: Lug
  • Panel Type: Siemens P1 Panelboards
  • Family: BQD Series
  • Weight: 1.1 lb


Product Identification
  • UPC: 783643277267
  • GTIN: 00783643277267
