Cutler Hammer BQC220220 - Molded Case Breaker 20A 2P 240V
Cutler Hammer BQC220220 - Molded Case Breaker 20A 2P 240V
Cutler Hammer BQC220220 - Molded Case Breaker 20A 2P 240V
Cutler Hammer BQC220220 - Molded Case Breaker 20A 2P 240V
Cutler Hammer BQC220220 - Molded Case Breaker 20A 2P 240V
Cutler Hammer BQC220220 - Molded Case Breaker 20A 2P 240V

Cutler Hammer BQC220220 - Molded Case Breaker 20A 2P 240V

Cutler Hammer
Price
Save $399.71
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Cutler Hammer BQC220220 is a molded case circuit breaker designed to provide reliable overcurrent protection for single-phase, 240V AC branch circuits. It features a 20A thermal-magnetic trip unit with long-time and instantaneous (LI) protection functions and a 10kA interrupting rating at 240V. The compact, plug-in unit measures 2" x 2.4" x 3" (LxHxW), weighs 0.75 lb, and utilizes lug terminals compatible with copper or aluminum wire from AWG 14 to 4. It is UL 489 listed and HACR rated for use in heating, air conditioning, and refrigeration equipment, making it suitable for commercial and light industrial panelboards.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Plug-In Connection
  • Voltage Rating: 240V AC
  • Current Rating: 20A
  • Dimensions: 2 in (Depth) x 2.4 in (Height) x 3 in (Width)
  • Standards: UL Listed (UL 489), HACR Rated, Federal Spec W-C386
  • Applications: Branch Circuit Protection in Commercial/Industrial Panelboards
  • Switch Type: Circuit Breaker
  • Configuration: Plug-In
  • Phase: 1
  • AIC rating: 10kA @ 240V
  • Connection: Plug-In
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: Long-Time and Instantaneous Trip (LI)
  • Terminal Connection: Lug
  • Wire Size: AWG 14 to AWG 4, Cu/Al
  • Certification: UL 489
  • Family: BQ Series
  • Weight: 0.75 lb
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 786676371841
  • GTIN: 00786676371841
