Cutler Hammer BQC215220 - 2-Pole Circuit Breaker 20A 240V 10kAIC
Cutler Hammer BQC215220 - 2-Pole Circuit Breaker 20A 240V 10kAIC
Cutler Hammer BQC215220 - 2-Pole Circuit Breaker 20A 240V 10kAIC
Cutler Hammer BQC215220 - 2-Pole Circuit Breaker 20A 240V 10kAIC
Cutler Hammer BQC215220 - 2-Pole Circuit Breaker 20A 240V 10kAIC
Cutler Hammer BQC215220 - 2-Pole Circuit Breaker 20A 240V 10kAIC

Cutler Hammer BQC215220 - 2-Pole Circuit Breaker 20A 240V 10kAIC

Cutler Hammer
Price
Save $377.89
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Cutler Hammer BQC215220 is a two-pole molded case circuit breaker designed to provide reliable overcurrent protection for single-phase 240V AC branch circuits. It features a 20A current rating and a 10kA interrupting capacity at 240V, utilizing a thermal-magnetic trip mechanism for both long-time delay and instantaneous short-circuit protection. The compact plug-in unit measures 3" x 3" x 2" (LxHxW), weighs 0.9 lb, and features lug terminals compatible with copper or aluminum wire from AWG 14 to AWG 4. It is UL 489 listed and HACR rated for heating, air conditioning, and refrigeration equipment, ensuring compliance with industry safety standards for commercial and light industrial panelboards.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Plug-In Connection
  • Voltage Rating: 240V AC
  • Current Rating: 20A
  • Dimensions: 3 in (Length/Depth) x 3 in (Height) x 2 in (Width)
  • Standards: UL Listed (UL 489), HACR Rated, Federal Specifications Classification W-C379
  • Applications: Branch circuit protection in commercial and light industrial panelboards
  • Switch Type: Circuit Breaker
  • Configuration: Plug-In
  • Phase: 1
  • AIC Rating: 10kA @ 240V
  • Connection: Plug-In, Lug Terminal
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: LI (Long-Time and Instantaneous Trip)
  • Wire Size: AWG 14 to AWG 4, Copper or Aluminum
  • Certification: UL 489
  • Weight: 0.9 lb


Product Identification
  • UPC: 786676005982
  • GTIN: 00786676005982
