Siemens BQ3B10000S01 - Molded Case Circuit Breaker 100A 3P 10kA
Siemens BQ3B10000S01 - Molded Case Circuit Breaker 100A 3P 10kA

Siemens BQ3B10000S01 - Molded Case Circuit Breaker 100A 3P 10kA

Siemens
Price
Save $528.68
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens BQ3B10000S01 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in three-phase electrical systems. It features a 100A current rating and a 240V voltage rating, housed within a compact 125A frame with dimensions of 2.563" x 4.00" x 3.972" and a weight of 1.323 lb. This thermal-magnetic, bolt-on breaker is constructed for durability with lug terminals and operates effectively across a temperature range of -25°C to 70°C. It complies with key industry standards, being UL Listed, CSA certified, and HACR rated, with an interrupting capacity of 10kA at 240V. This unit is typically applied in Siemens panelboards and is supplied complete with a non-interchangeable 120V shunt trip for remote circuit opening.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Shunt Trip
  • Voltage Rating: 240V AC
  • Current Rating: 100A
  • Dimensions: 2.563" H x 4.00" W x 3.972" D
  • Standards: UL Listed, CSA, HACR Rated
  • Applications: Siemens Panelboards, Three-Phase Systems
  • Switch Type: Circuit Breaker
  • Configuration: Bolt-on
  • Coil Voltage Maximum: 120V (Shunt Trip)
  • Temp Rating: -25°C to 70°C
  • Shipping Dimensions: 2.563" x 4.00" x 3.972"
  • Phase: 3
  • Voltage: 240V
  • Amperage: 100A
  • AIC rating: 10kA @ 240V
  • Connection: Bolt-on
  • Poles: 3
  • Protection: Thermal Magnetic
  • Functions: Long-Time and Instantaneous (LI)
  • Frame Size: 125A/BQ
  • Trip Type: Thermal Magnetic
  • Panel Type: Siemens Panelboards
  • Breaker Type: Shunt Trip
  • Control Voltage Minimum: 120V (Shunt Trip)
  • Control Voltage Maximum: 120V (Shunt Trip)
  • MCM Size: Wire Range: 8 AWG Min, 4 AWG (Al) / 6 AWG (Cu) Max
  • Terminal Connection: Lug
  • Certification: CSA, HACR, UL
  • Family: BQ Series
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643000858
  • GTIN: 00783643000858
