Siemens BQ3B04000S01 - Molded Case Breaker 40A 3P 240V
Siemens BQ3B04000S01 - Molded Case Breaker 40A 3P 240V

Siemens BQ3B04000S01 - Molded Case Breaker 40A 3P 240V

Siemens
Price
Save $651.66
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens BQ3B04000S01 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in three-phase electrical systems. It features a 40A current rating and a 240V voltage rating, housed within a compact 125A frame with dimensions of 5.906 x 3.937 x 3.937 inches and a weight of 1.698 lb. The breaker is constructed with a thermal-magnetic trip unit for long-time and instantaneous protection, utilizing a bolt-on connection with lug terminals suitable for copper (AWG 8 to 6) or aluminum (AWG 8 to 4) conductors. It complies with UL, CSA, and HACR standards and is rated for an interrupting capacity of 10kA at 240V, operating reliably in ambient temperatures from -25°C to 70°C. This shunt trip breaker is typically applied in Siemens panelboards for industrial and commercial power distribution, where its integrated 120V shunt trip coil provides a means for remote circuit opening.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Trip, Shunt Trip
  • Voltage Rating: 240V AC
  • Current Rating: 40A
  • Frame Size: 125A/BQ
  • Poles: 3
  • AIC Rating: 10kA @ 240V
  • Connection: Bolt-on, Lug Terminal
  • Wire Size: AWG 8 to 6 (Copper), AWG 8 to 4 (Aluminum)
  • Protection: Thermal-Magnetic (Long Time & Instantaneous)
  • Standards: UL Listed, CSA Certified, HACR Rated
  • Phase: 3
  • Dimensions: 5.906" x 3.937" x 3.937" (150mm x 100mm x 100mm)
  • Weight: 1.698 lb (0.77 kg)
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Panel Type: Siemens Panelboards
  • Breaker Type: Shunt Trip (with 120V coil)
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643237841
  • GTIN: 00783643237841
