Siemens BQ3B01500S01 - 3-Pole Molded Case Breaker 15A 240V
Siemens BQ3B01500S01 - 3-Pole Molded Case Breaker 15A 240V

Siemens BQ3B01500S01 - 3-Pole Molded Case Breaker 15A 240V

Siemens
Price
Save $480.13
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens BQ3B01500S01 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in three-phase electrical systems. It features a 15A thermal-magnetic trip unit with long-time and instantaneous (LI) functions, rated for 240V AC systems with a 10kA interrupting capacity at that voltage. The compact, bolt-on unit measures 150 x 100 x 70 mm (5.906" x 3.937" x 2.756") and weighs 1.609 lb, constructed with lug terminals compatible with wire sizes from 8 AWG to 4 AWG for aluminum or 6 AWG for copper. It is certified to UL, CSA, and HACR standards for safety and is engineered for operation in temperatures ranging from -25°C to 70°C (-13°F to 158°F). This breaker is typically integrated into Siemens panelboards for commercial and industrial power distribution, and it includes a factory-installed, non-interchangeable 120V shunt trip coil for remote tripping capability.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker with Thermal-Magnetic Protection and Shunt Trip
  • Voltage Rating: 240V AC
  • Current Rating: 15A
  • Frame Size: 125A/BQ
  • Poles: 3
  • Phase: 3
  • AIC Rating: 10kA @ 240V
  • Connection: Bolt-on with Lug Terminals
  • Functions: LI (Long-Time and Instantaneous)
  • Protection: Thermal Magnetic
  • Breaker Type: Shunt Trip (120V Coil)
  • Panel Type: Siemens Panelboards
  • Standards: UL Listed, CSA Certified, HACR Rated
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Dimensions: 150 x 100 x 70 mm (5.906" x 3.937" x 2.756")
  • Weight: 1.609 lb
  • MCM Size: Min. 8 AWG, Max. 4 AWG (Al) / 6 AWG (Cu)
  • Terminal Connection: Lug
  • Certification: CSA, HACR, UL
  • Family: BQ Series
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643237810
  • GTIN: 00783643237810
