Siemens BQ2B10000S01 - Molded Case Circuit Breaker 100A 2P (10kA AIC)
Siemens BQ2B10000S01 - Molded Case Circuit Breaker 100A 2P (10kA AIC)

Siemens BQ2B10000S01 - Molded Case Circuit Breaker 100A 2P (10kA AIC)

Siemens
Price
Save $856.49
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens BQ2B10000S01 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in industrial and commercial electrical systems. It features a 100A current rating and a 240V voltage rating, housed within a compact 125A frame with dimensions of 2.563" x 3.00" x 3.972" and a weight of 0.926 lb. The breaker is constructed for bolt-on connection with lug terminals, supports wire sizes from 8 AWG to 2 AWG (Al) or 4 AWG (Cu), and operates on a single-phase system. It complies with industry standards, being UL Listed, CSA certified, and HACR rated for use in heating, air conditioning, and refrigeration equipment. This thermal-magnetic shunt trip breaker, which includes a non-interchangeable 120V shunt trip coil, is typically applied in Siemens panelboards for feeder and branch circuit protection, offering a 10kA interrupting capacity at 240V and an operational temperature range of -25°C to 70°C.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic Protection with Shunt Trip
  • Voltage Rating: 240V AC
  • Current Rating: 100A
  • Frame Size: 125A/BQ
  • Poles: 2
  • AIC Rating: 10kA @ 240V
  • Connection: Bolt-on, Lug Terminal
  • Phase: 1
  • Functions: Long Time and Instantaneous Trip
  • Protection: Thermal Magnetic
  • Breaker Type: Shunt Trip (with 120V coil)
  • Panel Type: Siemens Panelboards
  • Standards & Certification: UL Listed, CSA, HACR Rated
  • Temp Rating: -25°C to 70°C
  • Dimensions: 2.563" x 3.00" x 3.972"
  • Weight: 0.926 lb
  • MCM Size / Wire Range: Min. 8 AWG, Max. 2 AWG (Al) or 4 AWG (Cu)
  • Family: BQ Series
  • Country of Origin: Mexico


Product Identification
  • UPC: 078364323780
  • GTIN: 00783643237803
