Siemens
Price
Save $505.84
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens BQ2B080 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in single-phase electrical systems. It features an 80A current rating and a 120/240V voltage rating, housed within a compact, bolt-on unit measuring 2.756" x 1.969" x 3.937" (70mm x 50mm x 100mm) and weighing 0.728 lb. This thermal-magnetic breaker is HACR rated and UL Listed/CSA certified for safety, ensuring compliance with industry standards for use in Siemens panelboards and similar industrial and commercial distribution equipment.

Key Features & Specifications
  • Type: Molded Case, Thermal Magnetic Protection, Standard Breaker Type
  • Voltage Rating: 120/240V AC
  • Current Rating: 80A
  • Frame Size: 125A/BQ
  • Poles: 2
  • AIC Rating: 10kA @ 240V
  • Connection: Bolt-on, Lug Terminal
  • Functions: LI (Long-Time and Instantaneous Trip)
  • Phase: 1
  • Dimensions: 2.756" x 1.969" x 3.937" (70mm x 50mm x 100mm)
  • Weight: 0.728 lb
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • MCM Size / Wire Range: Min. 12 AWG (Al) / 14 AWG (Cu), Max. 6 AWG
  • Panel Type: Siemens Panelboards
  • Standards & Certification: HACR Rated, UL Listed, CSA
  • Country of Origin: Mexico


Product Identification
  • UPC: 078364316123
  • GTIN: 00783643161238
  • Family: BQ Series
