Siemens BQ2B02000S01 - Molded Case Breaker 20A 2P (Shunt Trip)
Siemens BQ2B02000S01 - Molded Case Breaker 20A 2P (Shunt Trip)

Siemens BQ2B02000S01 - Molded Case Breaker 20A 2P (Shunt Trip)

Siemens
Price
Save $1.57
/
Condition
  • Low stock - 9 items left
  • Backordered, shipping soon
Call for Price
Siemens BQ2B02000S01 is a molded case circuit breaker designed for providing reliable overcurrent protection in single-phase electrical systems. It features a 20A current rating and a 120/240V voltage rating, housed within a compact 125A frame with dimensions of 2.571" x 3.00" x 3.736" and a weight of 0.926 lb. The breaker is constructed with a thermal-magnetic trip unit for LI (Long-time and Instantaneous) protection and a bolt-on connection with lug terminals, accepting wire sizes from 8 AWG to 2 AWG (Al) or 4 AWG (Cu). It complies with key industry standards, being UL Listed, CSA certified, and HACR rated, with an interrupting capacity of 10kA at 240V. This shunt trip breaker, which includes a non-interchangeable 120V shunt trip coil and operates in a temperature range of -25°C to 70°C, is typically applied in Siemens panelboards for commercial and light industrial distribution.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, BQ Series, Thermal-Magnetic Protection, Shunt Trip
  • Voltage Rating: 120/240V AC
  • Current Rating: 20A
  • Frame Size: 125A/BQ
  • Poles: 2
  • AIC Rating: 10kA @ 240V
  • Connection: Bolt-on, Lug Terminal
  • Phase: 1
  • Functions: LI (Long-Time & Instantaneous Trip)
  • Protection: Thermal Magnetic
  • Panel Type: Siemens Panelboards
  • Breaker Type: Shunt Trip (with 120V coil)
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • MCM Size / Wire Range: Min 8 AWG, Max 2 AWG (Al) / 4 AWG (Cu)
  • Dimensions: 2.571" L x 3.00" W x 3.736" H
  • Weight: 0.926 lb
  • Standards & Certification: UL Listed, CSA, HACR Rated
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643237728
  • GTIN: 00783643237728
