Siemens BQ2B01500S01 - Shunt Trip Breaker 15A 2-Pole
Siemens BQ2B01500S01 - Shunt Trip Breaker 15A 2-Pole

Siemens BQ2B01500S01 - Shunt Trip Breaker 15A 2-Pole

Siemens
Price
Save $305.78
/
Condition
  • Low stock - 5 items left
  • Backordered, shipping soon
Call for Price
Siemens BQ2B01500S01 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in single-phase electrical systems. It features a 15A thermal-magnetic trip unit with long-time and instantaneous functions, rated for 120/240V AC systems with a 10kA interrupting capacity at 240V. The compact, bolt-on unit measures 150 x 100 x 70 mm (5.906" x 3.937" x 2.756"), weighs 0.904 lb, and is constructed with lug terminals compatible with wire sizes from 8 AWG to 2 AWG (Al) or 4 AWG (Cu). It is certified to UL, CSA, and HACR standards for safety and is engineered for operation in temperatures from -25°C to 70°C (-13°F to 158°F). This shunt trip breaker is typically installed in Siemens panelboards for applications requiring remote tripping capability.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Shunt Trip
  • Voltage Rating: 120/240V AC
  • Current Rating: 15A
  • Frame Size: 125A/BQ
  • Poles: 2
  • AIC Rating: 10kA @ 240V
  • Connection: Bolt-on, Lug Terminal
  • Phase: 1
  • Functions: Long Time and Instantaneous Trip
  • Standards & Certification: UL Listed, CSA, HACR Rated
  • Panel Type: Siemens Panelboards
  • Operating Temperature: -25°C to 70°C (-13°F to 158°F)
  • Dimensions: 150 x 100 x 70 mm (5.906" x 3.937" x 2.756")
  • Weight: 0.904 lb
  • Wire Size (MCM): Min. 8 AWG, Max. 2 AWG (Aluminum) or 4 AWG (Copper)
  • Additional Info: Complete with non-interchangeable 120V shunt trip


Product Identification
  • UPC: 783643237711
  • GTIN: 00783643237711
