Cutler-Hammer BQ215230 - 2-Pole Circuit Breaker (30A, 240V)
Cutler-Hammer BQ215230 - 2-Pole Circuit Breaker (30A, 240V)

Cutler-Hammer BQ215230 - 2-Pole Circuit Breaker (30A, 240V)

Cutler Hammer
Price
Save $347.07
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
The Cutler-Hammer BQ215230 is a two-pole molded case circuit breaker designed to provide reliable overcurrent and short-circuit protection for 240V AC branch circuits. It features a 30A continuous current rating and a 10kA interrupting capacity at 240V, utilizing a thermal-magnetic trip mechanism for both long-time delay and instantaneous response. The compact unit measures 3" x 3" x 2" (L/D x H x W), weighs 0.7 lb, and is constructed with lug terminals compatible with copper or aluminum conductors from AWG 14 to AWG 4. It is fully compliant with UL 489 and CSA standards, is HACR rated, and meets Federal Specification W-C377 for use in Type BR loadcenters. This feed-thru configuration breaker is typically applied in single-phase industrial and commercial electrical distribution panels.

Key Features & Specifications
  • Type: Two-pole, molded case, thermal-magnetic circuit breaker with feed-thru connection
  • Voltage Rating: 240V AC
  • Current Rating: 30A
  • Dimensions: 3 in (Length/Depth) x 3 in (Height) x 2 in (Width)
  • Standards: UL Listed, CSA Certified, HACR Rated, meets Federal Specification W-C377
  • Applications: Overcurrent protection in single-phase Type BR loadcenters for industrial and commercial distribution
  • Switch Type: Circuit Breaker
  • Configuration: Feed-Thru
  • Phase: 1
  • AIC rating: 10kA @ 240V
  • Connection: Lug Terminal
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Panel Type: Type BR Loadcenters
  • Breaker Type: Molded Case
  • Wire Size: AWG 14 to AWG 4, Cu/Al
  • Certification: UL 489
  • Family: BQ Series
  • Item Subcategory: Molded Case
  • Country of Origin: Dominican Republic
  • Weight: 0.7 lb


Product Identification
  • UPC: 786676004404
  • GTIN: 00786676004404
