Siemens BQ1B060H - Molded Case Circuit Breaker 60A 1P 120V
Siemens BQ1B060H - Molded Case Circuit Breaker 60A 1P 120V

Siemens BQ1B060H - Molded Case Circuit Breaker 60A 1P 120V

Siemens
Price
Save $58.41
/
Condition
  • Low stock - 2 items left
  • Backordered, shipping soon
Call for Price
Siemens BQ1B060H is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in single-phase electrical systems. It features a 60A current rating and a 120V voltage rating, housed within a compact, bolt-on frame measuring 3.937 x 2.756 x 0.787 inches and weighing 0.309 lb. This thermal-magnetic breaker, with its 22kA interrupting capacity at 120V, is CSA Certified, HACR Rated, and UL Listed for compliance, making it suitable for installation in Siemens panelboards and similar industrial or commercial applications.

Key Features & Specifications
  • Type: Molded Case, Thermal Magnetic, High Interrupting Capacity (BQH)
  • Voltage Rating: 120V AC
  • Current Rating: 60A
  • Frame Size: 125A/BQH
  • AIC Rating: 22kA @ 120V
  • Poles: 1
  • Phase: 1
  • Connection: Bolt-on with Lug Terminal
  • Protection Functions: LI (Long-Time and Instantaneous Trip)
  • Standards & Certification: CSA Certified, HACR Rated, UL Listed
  • Dimensions: 3.937" H x 2.756" W x 0.787" D (100mm x 70mm x 20mm)
  • Weight: 0.309 lb
  • Wire Size Range (MCM): Minimum 12 AWG (Al) / 14 AWG (Cu), Maximum 6 AWG
  • Panel Type: Siemens Panelboards
  • Family: BQ Series
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643161559
  • GTIN: 00783643161559
