Siemens BQ1B035H - Molded Case Circuit Breaker 35A 1P (22kA AIC)
Siemens BQ1B035H - Molded Case Circuit Breaker 35A 1P (22kA AIC)

Siemens BQ1B035H - Molded Case Circuit Breaker 35A 1P (22kA AIC)

Siemens
Price
Save $63.67
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens BQ1B035H is a molded case circuit breaker designed for providing reliable overcurrent protection in single-phase electrical systems. It features a 35A current rating and a 120V AC voltage rating, housed in a compact, durable frame measuring 2.563" x 1.00" x 3.122" and weighing 0.3 lb. This thermal-magnetic breaker utilizes a bolt-on connection with lug terminals and offers LI (Long-time and Instantaneous) trip functions for coordinated protection. It is CSA Certified, HACR Rated, and UL Listed, ensuring compliance with North American safety standards for use in Siemens panelboards and similar industrial and commercial applications where a 22kA interrupting capacity at 120V is required.

Key Features & Specifications
  • Type: BQH Series Molded Case Circuit Breaker, Thermal-Magnetic Protection
  • Voltage Rating: 120V AC
  • Current Rating: 35A
  • Dimensions: 2.563" H x 1.00" W x 3.122" D (65.1mm x 25.4mm x 79.3mm)
  • Standards: CSA Certified, HACR Rated, UL Listed
  • Applications: Siemens Panelboards, Commercial and Industrial Distribution
  • Switch Type: Circuit Breaker
  • Configuration: Bolt-On
  • Phase: 1
  • AIC Rating: 22kA @ 120V
  • Connection: Bolt-On
  • Poles: 1
  • Protection: Thermal Magnetic
  • Functions: LI (Long-Time and Instantaneous)
  • Panel Type: Siemens Panelboards
  • Breaker Type: Molded Case
  • Terminal Connection: Lug
  • Certification: CSA, HACR, UL
  • Family: BQ Series
  • Country of Origin: Mexico
  • Weight: 0.3 lb


Product Identification
  • UPC: 783643088368
  • GTIN: 00783643088368
