Schneider Electric
Price
Save $1,516.10
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
The Schneider Electric BJA36100 is a Powerpact molded case circuit breaker designed to provide reliable overcurrent and short-circuit protection for three-phase industrial power distribution systems. It features a 100A current rating and a 600V voltage rating, housed within a compact 125A/BJ frame measuring 137 mm H x 81 mm W x 89 mm D and weighing 3.81 lb. The breaker utilizes a thermal-magnetic trip unit for long-time and instantaneous (LI) protection and is constructed for compliance with UL 489, IEC 60947-2, CSA, and other major international standards. Its I-Line style plug-in connection and aluminum mechanical lugs facilitate installation in electrical distribution equipment and industrial control panels, operating effectively in ambient temperatures from -25°C to 70°C.

Key Features & Specifications
  • Type: Powerpact BJA, Molded Case, Thermal Magnetic Protection, Standard Breaker
  • Voltage Rating: 600V AC
  • Current Rating: 100A
  • Frame Size: 125A/BJ
  • Poles: 3
  • AIC Rating: 65kA at 480V
  • Connection: I-Line Style Plug-In; Terminal: Al Mechanical Lug (OFF End)
  • Phase Connection: ABC
  • Functions: LI (Long-Time and Instantaneous)
  • Wire Size: 14 AWG to 2/0 AWG (Aluminium/Copper)
  • Dimensions: 137 mm H x 81 mm W x 89 mm D (5.4 in x 3.2 in x 3.5 in)
  • Weight: 3.81 lb
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Standards: UL 489, IEC/EN 60947-2, CSA C22.2 No 5, NEMA AB1, GB 14048.2, NMX J-266
  • Certification: UL, IEC, CCC, EAC, CSA, NOM
  • Panel Type: Electrical Distribution Equipment, Industrial Control Panels
  • Country of Origin: Mexico


Product Identification
  • UPC: 785901014683
  • GTIN: 03606481185921
