Square D BGA36040 is a three-pole molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in industrial power distribution systems. It features a 40A current rating and a 600V AC voltage rating, housed within a compact 125A/BG frame measuring 137 mm H x 81 mm W x 89 mm D and weighing 3.801 lb. The breaker is constructed with thermal-magnetic LI (Long-time and Instantaneous) trip protection and utilizes an I-Line style plug-in connection with aluminum mechanical lugs, complying with UL 489, IEC 60947-2, CSA C22.2 No. 5, and other international standards. It is engineered for a wide operating temperature range of -25°C to 70°C and is typically applied in electrical distribution equipment and industrial control panels requiring a 35kA interrupting capacity at 480V.

Key Features & Specifications
  • Type: BGA, Standard, Molded Case Circuit Breaker with Thermal-Magnetic Protection
  • Voltage Rating: 600V AC
  • Current Rating: 40A
  • Dimensions: 137 mm H x 81 mm W x 89 mm D (5.4 in x 3.2 in x 3.5 in)
  • Standards: UL 489, IEC 60947-2, CSA C22.2 No. 5, NEMA AB1, GB 14048.2, NMX J-266
  • Applications: Electrical Distribution Equipment, Industrial Control Panels
  • Switch Type: Circuit Breaker
  • Configuration: Plug-In
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Shipping Dimensions: See Product Dimensions
  • Phase: 3
  • Amperage: 40A
  • AIC Rating: 35kA @ 480V
  • Connection: I-Line Style Plug-In
  • Poles: 3
  • Protection: Thermal Magnetic
  • Functions: LI - Long-Time and Instantaneous
  • Frame Size: 125A/BG
  • Trip Type: Thermal-Magnetic
  • Panel Type: Electrical Distribution Equipment, Industrial Control Panels
  • Breaker Type: Standard
  • MCM Size: Min. Wire Size 14 AWG, Max. Wire Size 2 AWG
  • Mounting: Plug-In
  • Certification: UL, IEC, CCC, EAC, CSA, NOM
  • Circuit Breaker Mounting Style: Plug-In
  • Terminal Connection: Al Mechanical Lug OFF End, I-Line ON End
  • Phase Connection: ABC
  • Compatible Frames: I-Line
  • Wire Size: AWG 14 to AWG 2/0 (Aluminium/Copper)
  • Weight: 3.801 lb


Product Identification
  • UPC: 785901011408
  • GTIN: 03606481153753
