Square D
Price
Save $822.52
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Square D BGA36030 is a three-pole molded case circuit breaker designed for reliable overcurrent protection in three-phase industrial power distribution systems. It features a 30A current rating and a 600V voltage rating, housed within a compact 125A/BG frame measuring 137 mm H x 81 mm W x 89 mm D and weighing 4.23 lb. The breaker utilizes a thermal-magnetic trip mechanism for long-time and instantaneous (LI) protection, offers a 35kA interrupting capacity at 480V, and operates across a temperature range of -25 to 70 °C. It complies with UL 489, CSA C22.2 No 5, IEC 60947-2, and other international standards, making it suitable for installation in electrical distribution equipment and industrial control panels. Its I-Line plug-in connection and aluminum mechanical lug terminals facilitate efficient integration and termination for wire sizes from 14 AWG to 2/0 AWG.

Key Features & Specifications
  • Type: Three-pole, thermal-magnetic molded case circuit breaker with I-Line plug-in connection
  • Voltage Rating: 600V AC
  • Current Rating: 30A
  • Frame Size: 125A/BG
  • AIC Rating: 35kA at 480V AC
  • Poles: 3
  • Connection: I-Line Style Plug-In
  • Terminal Connection: Aluminum Mechanical Lug (OFF End), I-Line (ON End)
  • Protection: Thermal Magnetic (Long-Time and Instantaneous)
  • Wire Size: 14 AWG to 2/0 AWG (aluminium/copper)
  • Phase Connection: ABC
  • Dimensions: 137 mm H x 81 mm W x 89 mm D (5.4 in x 3.2 in x 3.5 in)
  • Weight: 4.23 lb
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Standards: UL 489, CSA C22.2 No 5, NEMA AB1, IEC/EN 60947-2, NMX J-266, GB 14048.2
  • Certification: UL, CSA, IEC, CCC, EAC, NOM
  • Panel Type: Electrical Distribution Equipment, Industrial Control Panels
  • Breaker Type: Standard
  • Family: Powerpact
  • Country of Origin: Mexico


Product Identification
  • UPC: 785901003892
  • GTIN: 03606481153715
