Square D
Price
Save $852.54
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Square D BGA36020 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in three-phase electrical systems. It features a 20A current rating and a 600V voltage rating, housed within a compact 125A/BG frame measuring 137 mm H x 81 mm W x 89 mm D and weighing 4.2 lb. This thermal-magnetic breaker is constructed for compliance with UL 489, IEC 60947-2, CSA C22.2 No 5, and other international standards, ensuring suitability for industrial control panels and electrical distribution equipment. Its I-Line style plug-in connection and aluminum mechanical lugs facilitate efficient installation, supporting wire sizes from 14 AWG to 2/0 AWG for both copper and aluminum conductors.

Key Features & Specifications
  • Type: BGA Standard Molded Case Circuit Breaker, Thermal-Magnetic Protection
  • Voltage Rating: 600V AC
  • Current Rating: 20A
  • Frame Size: 125A/BG
  • Poles: 3
  • AIC Rating: 35kA at 480V
  • Connection: I-Line Style Plug-In; Terminal: Al Mechanical Lug OFF End
  • Phase Connection: ABC
  • Functions: LI (Long-Time and Instantaneous)
  • Wire Size: AWG 14 to AWG 2/0 (aluminium/copper)
  • Temp Rating: -25 to 70 °C (-13 to 158 °F)
  • Dimensions: 137 mm H x 81 mm W x 89 mm D (5.4 in x 3.2 in x 3.5 in)
  • Weight: 4.2 lb
  • Standards: UL 489, IEC/EN 60947-2, CSA C22.2 No 5, GB 14048.2, NMX J-266
  • Certification: UL, IEC, CCC, EAC, CSA, NOM
  • Panel Type: Electrical Distribution Equipment, Industrial Control Panels


Product Identification
  • UPC: 785901010784
  • GTIN: 03606481153678
