Siemens
Price
Save $945.76
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens BE240 is a molded case circuit breaker designed for ground fault equipment protection in single-phase electrical systems. It features a 40A current rating and a 120/240V voltage rating, housed within a compact, bolt-on frame measuring 5.906 x 2.756 x 2.756 inches and weighing 1.036 lb. The breaker is constructed for reliable thermal-magnetic protection with long-time and instantaneous trip functions, complying with CSA, HACR, NOM, and UL standards. It is typically applied in Siemens P1 panelboards for commercial and light industrial applications, offering a 10kA interrupting capacity at 240V and an operational temperature range of -25 to 70 °C.

Key Features & Specifications
  • Type: BLE Molded Case Circuit Breaker, Thermal Magnetic Protection, Ground Fault Equipment Protection
  • Voltage Rating: 120/240V AC
  • Current Rating: 40A
  • Dimensions: 5.906 x 2.756 x 2.756 inch (150 x 70 x 70 mm)
  • Standards: CSA Certified, HACR Rated, NOM Certified, UL Listed
  • Applications: Siemens P1 Panelboards, Commercial, Light Industrial
  • Switch Type: Circuit Breaker
  • Configuration: Bolt-on
  • Temp Rating: -25 to 70 °C (-13 to 158 °F)
  • Shipping Dimensions: 5.906 x 2.756 x 2.756 inch
  • Phase: 1
  • Voltage: 120/240V
  • Amperage: 40A
  • AIC rating: 10kA @ 240V
  • Connection: Bolt-on
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: LI - Long-Time and Instantaneous Trip
  • Frame Size: 60A/BLE
  • Breaker Type: Ground Fault Equipment Protection
  • MCM Size: Min. Wire Size 12 AWG (Al), 14 AWG (Cu); Max. Wire Size 6 AWG
  • Terminal Connection: Lug
  • Panel Type: Siemens P1 Panelboards
  • Certification: CSA Certified, HACR Rated, NOM Certified, UL Listed
  • Weight: 1.036 lb


Product Identification
  • UPC: 783643274136
  • GTIN: 00783643274136
