Square D BDA36035 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in three-phase electrical systems. It features a 35A current rating and a 600V voltage rating, housed within a compact 125A/BD frame measuring 137 mm H x 81 mm W x 89 mm D and weighing 4.12 lb. The breaker is constructed with thermal-magnetic trip protection for both long-time and instantaneous functions and complies with UL 489, IEC 60947-2, CSA, and other international standards. It is typically applied in industrial control panels and electrical distribution equipment, offering an interrupting capacity of 18kA at 480V and an operating temperature range of -25 to 70 °C.

Key Features & Specifications
  • Type: Standard thermal-magnetic molded case circuit breaker
  • Voltage Rating: 600V AC
  • Current Rating: 35A
  • Frame Size: 125A/BD
  • Poles: 3
  • Phase Connection: ABC
  • AIC Rating: 18kA @ 480V
  • Connection: I-Line ON End, Al Mechanical Lug OFF End
  • Protection: Thermal Magnetic (Long Time & Instantaneous Trip)
  • Wire Size: 14 AWG to 2/0 AWG (Aluminium/Copper)
  • MCM Size: 14 AWG Min, 2 AWG Max
  • Dimensions: 5.4 in (137 mm) H x 3.2 in (81 mm) W x 3.5 in (89 mm) D
  • Weight: 4.12 lb
  • Temp Rating: -25 to 70 °C (-13 to 158 °F)
  • Standards: UL 489, EN/IEC 60947-2, NEMA AB1, CSA C22.2 No. 5, NMX J-266, GB 14048.2
  • Certification: UL, IEC, CCC, EAC, CSA, NOM
  • Panel Type: Electrical Distribution Equipment, Industrial Control Panels
  • Breaker Type: Standard
  • Family: Powerpact
  • Country of Origin: Mexico


Product Identification
  • UPC: 78590105124
  • GTIN: 00785901051244
