Square D BDA260301 - Molded Case Circuit Breaker 30A 600V 2-Pole
Square D BDA260301 - Molded Case Circuit Breaker 30A 600V 2-Pole

Square D BDA260301 - Molded Case Circuit Breaker 30A 600V 2-Pole

Square D
Price
Save $372.22
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Square D BDA260301 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in industrial electrical systems. It features a 30A current rating and a 600V voltage rating, housed within a compact 125A/BD frame measuring 137 mm H x 54 mm W x 89 mm D and weighing 3.17 lb. This thermal-magnetic breaker is constructed for compliance with UL 489, IEC 60947-2, CSA C22.2 No 5, and other major international standards. Its I-Line connection and two-pole configuration make it suitable for installation in electrical distribution equipment and industrial control panels.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic Protection with Long Time and Instantaneous Trip Functions
  • Voltage Rating: 600V AC
  • Current Rating: 30A
  • Frame Size: 125A/BD
  • Poles: 2
  • AIC Rating: 18kA at 480V
  • Connection: I-Line ON End, Al Mechanical Lug OFF End
  • Phase: 1, AB Phase Connection
  • Wire Size: 14 AWG to 2/0 AWG (Aluminium/Copper)
  • Dimensions: 5.4 in (137 mm) H x 2.1 in (54 mm) W x 3.5 in (89 mm) D
  • Weight: 3.17 lb
  • Temp Rating: -25 to 70 °C (-13 to 158 °F)
  • Standards: UL 489, IEC/EN 60947-2, CSA C22.2 No 5, NEMA AB1, GB 14048.2, NMX J-266
  • Certification: UL, CSA, IEC, CCC, EAC, NOM
  • Breaker Type: Standard
  • Panel Type: Electrical Distribution Equipment, Industrial Control Panels


Product Identification
  • UPC: 785901013143
  • GTIN: 03606481152091
