Cutler Hammer BAB2110 - Molded Case Circuit Breaker 110A 2-Pole
Cutler Hammer BAB2110 - Molded Case Circuit Breaker 110A 2-Pole
Cutler Hammer BAB2110 - Molded Case Circuit Breaker 110A 2-Pole
Cutler Hammer BAB2110 - Molded Case Circuit Breaker 110A 2-Pole

Cutler Hammer BAB2110 - Molded Case Circuit Breaker 110A 2-Pole

Cutler Hammer
Price
Save $1,087.36
/
Condition
  • Low stock - 2 items left
  • Backordered, shipping soon
Call for Price
Cutler Hammer BAB2110 is a molded case circuit breaker designed for providing reliable overcurrent protection in industrial and commercial electrical systems. It features a 110A current rating and a 240V AC voltage rating for single-phase applications, housed in a compact bolt-on configuration measuring 3.8 in x 4.8 in x 2.2 in. The breaker utilizes a thermal-magnetic trip mechanism for both long-time and instantaneous protection, is HACR rated for HVAC equipment, and complies with UL and CSA standards. Its 10kA interrupting rating at 240V and operating temperature range of -25°C to 70°C make it suitable for panelboards, switchboards, and motor control centers.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Bolt-On Connection
  • Voltage Rating: 240V AC
  • Current Rating: 110A
  • Dimensions: 3.8 in (L) x 4.8 in (H) x 2.2 in (W)
  • Standards: HACR Rated
  • Applications: Panelboards, Switchboards, Motor Control Centers
  • Poles: 2
  • Phase: 1
  • AIC Rating: 10kA @ 240V
  • Connection: Bolt-On
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Wire Size: 14 AWG to 4 AWG (Aluminum/Copper)
  • Certification: UL Listed, CSA Certified
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Weight: 0.8 lb
  • Family: Quicklag
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 786679910795
  • GTIN: 00786679910795
