Cutler Hammer BAB1060 - Molded Case Breaker 60A 1P 240V (10kA AIC)
Cutler Hammer BAB1060 - Molded Case Breaker 60A 1P 240V (10kA AIC)
Cutler Hammer BAB1060 - Molded Case Breaker 60A 1P 240V (10kA AIC)
Cutler Hammer BAB1060 - Molded Case Breaker 60A 1P 240V (10kA AIC)

Cutler Hammer BAB1060 - Molded Case Breaker 60A 1P 240V (10kA AIC)

Cutler Hammer
Price
Save $72.93
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Cutler Hammer BAB1060 is a molded case circuit breaker designed for providing reliable overcurrent protection in single-phase industrial and commercial electrical systems. It features a 60A current rating and a 240V AC voltage rating, housed in a compact 3.7" x 4.6" x 1.2" bolt-on unit weighing 0.35 lb. The breaker is constructed with a thermal-magnetic trip mechanism providing both long-time and instantaneous (LI) protection, and it complies with UL and CSA standards while being HACR rated for HVAC equipment. Its 10kA interrupting rating at 240V and operating temperature range of -25°C to 70°C make it suitable for protecting feeder and branch circuits, typically accommodating wire sizes from 8 AWG to 1/0 AWG for aluminum or copper load connections.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Bolt-On Connection
  • Voltage Rating: 240V AC
  • Current Rating: 60A
  • Dimensions: 3.7 in (L) x 4.6 in (H) x 1.2 in (W)
  • Standards: HACR rated, UL Listed, CSA Certified
  • Applications: Industrial & Commercial Feeder/Branch Circuit Protection
  • Switch Type: Circuit Breaker
  • Configuration: Single Pole
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Shipping Dimensions: 3.7 in x 4.6 in x 1.2 in
  • Phase: 1
  • Voltage: 240V
  • Amperage: 60A
  • AIC rating: 10kA @ 240V
  • Connection: Bolt-On
  • Poles: 1
  • Protection: Thermal Magnetic
  • Functions: LI - Long-Time and Instantaneous Trip
  • Wire Size: 8 To 1/0 AWG (Aluminum/Copper Load)
  • Certification: UL Listed, CSA Certified
  • Family: Quicklag
  • Country of Origin: Dominican Republic
  • Weight: 0.35 lb


Product Identification
  • UPC: 786679301609
  • GTIN: 00786679301609
