Siemens B330HH - 3P Molded Case Breaker 30A 240V 65kA
Siemens B330HH - 3P Molded Case Breaker 30A 240V 65kA

Siemens B330HH - 3P Molded Case Breaker 30A 240V 65kA

Siemens
Price
Save $1,169.13
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens B330HH is a three-pole molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in three-phase industrial electrical systems. It features a 30A current rating and a 240V AC voltage rating, housed within a compact, bolt-on design measuring 2.563" x 3.00" x 3.122" and weighing 0.948 lb. This thermal-magnetic breaker, part of the BL Series, is constructed with lug terminals and complies with key industry standards including UL, CSA, and NOM. It is engineered for integration into Siemens P1 panelboards, offering a 65kA interrupting capacity at 240V to safeguard equipment in commercial and industrial power distribution applications.

Key Features & Specifications
  • Type: HBL Molded Case Circuit Breaker, Thermal-Magnetic Protection with Long-Time and Instantaneous (LI) Trip Functions
  • Voltage Rating: 240V AC
  • Current Rating: 30A
  • Frame Size: 125A/BL
  • Poles: 3
  • Phase: 3
  • AIC Rating: 65kA @ 240V
  • Connection: Bolt-on, Lug Terminal
  • Wire Size Range (MCM): Minimum 12 AWG (Al) / 14 AWG (Cu), Maximum 6 AWG
  • Dimensions: 2.563" H x 3.00" W x 3.122" D
  • Weight: 0.948 lb
  • Standards & Certification: UL Listed, CSA Certified, HACR Rated, NOM Certified
  • Panel Type: Compatible with Siemens P1 Panelboards
  • Breaker Type: Standard
  • Country of Origin: Mexico
  • Family: BL Series


Product Identification
  • UPC: 783643264229
  • GTIN: 00783643264229
