Siemens B325 - 3-Pole Circuit Breaker 25A 240V (10kA AIC)
Siemens B325 - 3-Pole Circuit Breaker 25A 240V (10kA AIC)
Siemens B325 - 3-Pole Circuit Breaker 25A 240V (10kA AIC)
Siemens B325 - 3-Pole Circuit Breaker 25A 240V (10kA AIC)
Siemens B325 - 3-Pole Circuit Breaker 25A 240V (10kA AIC)
Siemens B325 - 3-Pole Circuit Breaker 25A 240V (10kA AIC)

Siemens B325 - 3-Pole Circuit Breaker 25A 240V (10kA AIC)

Siemens
Price
Save $641.79
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens B325 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in three-phase electrical systems. It features a 25A current rating and a 240V AC voltage rating, housed within a compact, bolt-on unit measuring 2.563" x 3.00" x 3.122" and weighing 0.948 lb. The breaker utilizes a thermal-magnetic trip mechanism for both long-time and instantaneous protection, is certified to UL, CSA, and NOM standards, and is specifically compatible with Siemens P1 panelboards for industrial and commercial power distribution applications.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Bolt-on Connection
  • Voltage Rating: 240V AC
  • Current Rating: 25A
  • Dimensions: 2.563" H x 3.00" W x 3.122" D (65.1mm x 76.2mm x 79.3mm)
  • Standards: UL Listed, CSA Certified, HACR Rated, NOM Certified
  • Applications: Three-Phase Power Distribution in Siemens P1 Panelboards
  • Phase: 3
  • Poles: 3
  • AIC Rating: 10kA @ 240V AC
  • Frame Size: 125A/BL
  • Breaker Type: Standard
  • Connection: Bolt-on
  • Terminal Connection: Lug
  • Functions: Long Time and Instantaneous Trip
  • Protection: Thermal Magnetic
  • Panel Type: Siemens P1 Panelboards
  • MCM Size: Accepts 12-10 AWG Aluminum or 14-10 AWG Copper Wire
  • Weight: 0.948 lb (0.43 kg)
  • Family: BL Series
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643263703
  • GTIN: 00783643263703
