Siemens B28000S01 - Molded Case Breaker 80A 2-Pole (10kA AIC)
Siemens B28000S01 - Molded Case Breaker 80A 2-Pole (10kA AIC)

Siemens B28000S01 - Molded Case Breaker 80A 2-Pole (10kA AIC)

Siemens
Price
Save $804.74
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens B28000S01 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in single-phase electrical systems. It features a thermal-magnetic trip mechanism with long-time and instantaneous (LI) functions, rated for 80A at 120/240V AC with a 10kA interrupting capacity at 240V. The compact, bolt-on unit measures 2.563" x 3.00" x 3.122" and weighs 0.926 lb, constructed with lug terminals compatible with wire sizes from 6 to 12 AWG (Al) or 14 AWG (Cu). It is fully certified to UL, CSA, HACR, and NOM standards, ensuring compliance for industrial and commercial installations. This shunt trip breaker is typically applied within Siemens P1 panelboards for feeder and branch circuit protection.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, BL Series, Shunt Trip, Thermal Magnetic Protection
  • Voltage Rating: 120/240V AC
  • Current Rating: 80A
  • Frame Size: 125A/BL
  • Poles: 2
  • Phase: 1
  • AIC Rating: 10kA @ 240V
  • Connection: Bolt-on, Lug Terminal
  • Functions: LI (Long-Time and Instantaneous)
  • MCM/Wire Size: Min. 12 AWG (Al) / 14 AWG (Cu), Max. 6 AWG
  • Dimensions: 2.563" x 3.00" x 3.122"
  • Weight: 0.926 lb
  • Panel Type: Siemens P1 Panelboards
  • Standards/Certification: UL Listed, CSA Certified, HACR Rated, NOM Certified
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643268449
  • GTIN: 00783643268449
