Siemens B27000S01 - Molded Case Circuit Breaker 70A 2-Pole
Siemens B27000S01 - Molded Case Circuit Breaker 70A 2-Pole

Siemens B27000S01 - Molded Case Circuit Breaker 70A 2-Pole

Siemens
Price
Save $662.01
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens B27000S01 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in single-phase electrical systems. It features a 70A current rating and a voltage rating of 120/240V AC, housed within a compact, bolt-on frame measuring 2.563" x 3.00" x 3.122" and weighing 0.926 lb. This thermal-magnetic shunt trip breaker is constructed for durability with lug terminals and an operating temperature range of -25°C to 70°C, complying with CSA, HACR, NOM, and UL standards. It is typically applied in Siemens P1 panelboards for commercial and light industrial applications, offering a 10kA interrupting capacity at 240V.

Key Features & Specifications
  • Type: Molded Case, Thermal Magnetic Protection, Shunt Trip, BL Series
  • Voltage Rating: 120/240V AC
  • Current Rating: 70A
  • Frame Size: 125A/BL
  • Poles: 2
  • AIC Rating: 10kA @ 240V
  • Connection: Bolt-on, Lug Terminal
  • Phase: 1
  • Functions: LI (Long-Time and Instantaneous Trip)
  • Panel Type: Siemens P1 Panelboards
  • Standards: CSA Certified, HACR Rated, NOM Certified, UL Listed
  • Temp Rating: -25°C to 70°C
  • Dimensions: 2.563" x 3.00" x 3.122"
  • Weight: 0.926 lb
  • MCM Size: Wire Range 12-6 AWG (Al), 14-6 AWG (Cu)
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643268432
  • GTIN: 00783643268432
