Siemens B24000S01 - Molded Case Circuit Breaker 40A 2-Pole
Siemens B24000S01 - Molded Case Circuit Breaker 40A 2-Pole

Siemens B24000S01 - Molded Case Circuit Breaker 40A 2-Pole

Siemens
Price
Save $504.39
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens B24000S01 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in single-phase electrical systems. It features a 40A current rating and a 120/240V AC voltage rating, housed within a compact, bolt-on frame measuring 2.571" x 3.00" x 2.89" and weighing 0.926 lb. This thermal magnetic shunt trip breaker is constructed for operation from -25°C to 70°C and complies with key industry standards including UL, CSA, HACR, and NOM. It is typically applied in Siemens P1 panelboards for commercial and light industrial applications, offering a 10kA interrupting capacity at 240V AC with lug terminals that accommodate wire sizes from 6 to 12 AWG.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic Protection with Shunt Trip, BL Series
  • Voltage Rating: 120/240V AC
  • Current Rating: 40A
  • Dimensions: 2.571" H x 3.00" W x 2.89" D (65.3mm x 76.2mm x 73.4mm)
  • Standards: UL Listed, CSA Certified, HACR Rated, NOM Certified
  • Applications: Overcurrent protection in Siemens P1 Panelboards for commercial/industrial systems
  • Switch Type: Circuit Breaker
  • Configuration: Bolt-on
  • Phase: 1
  • Amperage: 40A
  • AIC Rating: 10kA @ 240V AC
  • Connection: Bolt-on, Lug Terminal
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: Long-Time and Instantaneous (LI) Trip
  • Frame Size: 125A/BL
  • Trip Type: Thermal Magnetic
  • Panel Type: Siemens P1 Panelboards
  • Breaker Type: Shunt Trip
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • MCM Size: Wire Range 6 AWG (Max) to 12 AWG (Al) / 14 AWG (Cu) (Min)
  • Mounting: Panel Mount
  • Certification: UL, CSA, HACR, NOM
  • Circuit Breaker Mounting Style: Bolt-on
  • Terminal Connection: Lug
  • Frequency Rating: 50/60 Hz
  • Phase Connection: Single Phase
  • Compatible Frames: Siemens BL Series
  • Item QTY: 1
  • Breaker Frame: BL
  • Weight: 0.926 lb


Product Identification
  • UPC: 783643268388
  • GTIN: 00783643268388
