Siemens B225 is a 2-pole, bolt-on circuit breaker designed for providing reliable overcurrent protection in single-phase industrial and commercial electrical systems. It features a 25A current rating and a 600V AC voltage rating, housed within a compact 125A/BL frame with dimensions of 100 x 70 x 50 mm (3.937 x 2.756 x 1.969 inches). This thermal-magnetic breaker, offering Long-Time and Instantaneous (LI) trip functions and a 10kA interrupting rating at 240V, is constructed for operation in temperatures from -25 to 70 °C and complies with CSA, HACR, and UL standards. It is specifically engineered for integration into Siemens P1 panelboards to protect branch circuits, supporting wire sizes from 12 AWG aluminum or 14 AWG copper up to a maximum of 10 AWG via its lug terminals.

Key Features & Specifications
  • Type: 2-pole, bolt-on, thermal-magnetic circuit breaker with Long-Time and Instantaneous (LI) trip functions
  • Voltage Rating: 600V AC
  • Current Rating: 25A
  • Frame Size: 125A/BL
  • Phase: 1
  • Poles: 2
  • AIC Rating: 10kA @ 240V
  • Connection: Bolt-on
  • Terminal Connection: Lug
  • Protection: Thermal Magnetic
  • MCM Size / Wire Range: Minimum 12 AWG (Al) / 14 AWG (Cu), Maximum 10 AWG
  • Temp Rating: -25 to 70 °C (-13 to 158 °F)
  • Dimensions: 100 x 70 x 50 mm (3.937 x 2.756 x 1.969 inches)
  • Weight: 0.617 lb
  • Panel Type: Siemens P1 Panelboards
  • Breaker Type: Standard
  • Standards & Certification: CSA, HACR, UL
  • Family: B Series
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643263543
  • GTIN: 00783643263543
