Siemens B115HH - Molded Case Circuit Breaker 15A 1-Pole
Siemens B115HH - Molded Case Circuit Breaker 15A 1-Pole
Siemens B115HH - Molded Case Circuit Breaker 15A 1-Pole
Siemens B115HH - Molded Case Circuit Breaker 15A 1-Pole
Siemens B115HH - Molded Case Circuit Breaker 15A 1-Pole
Siemens B115HH - Molded Case Circuit Breaker 15A 1-Pole
Siemens B115HH - Molded Case Circuit Breaker 15A 1-Pole
Siemens B115HH - Molded Case Circuit Breaker 15A 1-Pole

Siemens B115HH - Molded Case Circuit Breaker 15A 1-Pole

Siemens
Price
Save $266.76
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens B115HH is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in single-phase electrical systems. It features a 15A current rating and a 120V voltage rating, housed within a compact, bolt-on design measuring 2.563 x 1.00 x 3.122 inches and weighing 0.309 lb. This thermal magnetic breaker is constructed for operation in temperatures from -25°C to 70°C and complies with UL, CSA, HACR, and NOM standards. It is typically applied in Siemens P1 panelboards for commercial and light industrial applications, offering an interrupting capacity of 65kA at 240V.

Key Features & Specifications
  • Type: HBL Molded Case Circuit Breaker, Thermal Magnetic Protection with Long-Time and Instantaneous (LI) Trip
  • Voltage Rating: 120V
  • Current Rating: 15A
  • Frame Size: 125A/BL
  • AIC Rating: 65kA @ 240V
  • Poles: 1
  • Phase: 1
  • Connection: Bolt-on
  • Terminal Connection: Lug
  • MCM Size / Wire Range: Min. 12 AWG (Al) / 14 AWG (Cu), Max. 10 AWG
  • Dimensions: 2.563" x 1.00" x 3.122"
  • Weight: 0.309 lb
  • Operating Temperature: -25°C to 70°C (-13°F to 158°F)
  • Standards & Certification: UL Listed, CSA Certified, HACR Rated, NOM Certified
  • Panel Type: Compatible with Siemens P1 Panelboards
  • Breaker Type: Standard
  • Family: BL Series
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643264083
  • GTIN: 00783643264083
