Mersen ATQR3/16 - Class CC Fuse 3A 600V (200kA AIC Rating)

Mersen ATQR3/16 is a low voltage current-limiting fuse designed for protecting control circuits, transformers, and motor loads from short-circuit and overload conditions. It features a 600V AC voltage rating with a 3A current rating and 200kA interrupting capacity at 600V AC for reliable circuit protection. The fuse construction includes a single-barrel design with 0.41-inch diameter and 1-1/2-inch length, weighing 0.02 lb for compact installation. Certified to UL/CSA standards with Class CC rating, this fuse meets industrial safety requirements for electrical protection. Typical applications include industrial control panels, motor branch circuits, and transformer protection in commercial and manufacturing facilities.

Key Features & Specifications

• Type: ATQR current-limiting fuse, single barrel design
• Voltage Rating: 600V AC
• Current Rating: 3A
• Dimensions: 1-1/2 inch length, 0.41 inch diameter
• Standards: UL/CSA certified
• Applications: Control circuits, transformers, motor loads
• AIC rating: 200kA@600V AC
• Class Rating: CC
• Barrels: 1
• Weight: 0.02 lb
• Family: Amp-Trap 2000
• Country of Origin: Mexico

Product Identification

• UPC: 78200190629
• GTIN: 00782001906290
